Form’it!™ Tray

Specifications

TECHNICAL DATA

• The Form’it!™ Tray machine gathers 25 years of expertise in automation equipment to meet your unique production environment.
• The Form’it!™ Tray machine is available in 3 models (200, 300,350).
• The Form’it!™ Tray range handles a large number of different sizes with a high degree of reliability.
• Ergonomic and motorized ‘walk in’ magazineup to 25mm with “S” frame
• Accurate control of the blank with 4 snap-lock clipsup to 55mm with “M” and “L” frame
• Retractable forming cavity, ensuring that glue is dispensed without smearing
• Disposal of ready trays directly onto the customer’s conveyor.
• Form’it!™ Tray 200
• Machine dimensions (mm):
• 2307 x 2615 x 2160
• Carton dimensions:
• Minimum size (outside – mm) : 280 x 200 x 40
• Maximum size (outside – mm) : 600 x 400 x 200
• Form’it!™ Tray 300
• Machine dimensions (mm):
• 3330 x 1980 x 1800
• Carton dimensions:
• Minimum size (outside – mm) : 280 x 200 x 80
• Maximum size (outside – mm) : 600 x 400 x 300
• Form’it!™ Tray 350
• Machine dimensions (mm):
• 3530 x 2080 x 1800
• Carton dimensions:
• Minimum size (outside – mm) : 280 x 200 x 80
• Maximum size (outside – mm) : 600 x 400 x 350
